Home > Collections > Cove > Cove 6" LED Recessed Downlight 4000K
Cove
6" LED Recessed Downlight 4000K
Cove
Model: SM567798WTWT
Sizing: L6.75" x W6.75" x H3.75"
Finish: White
Shade: White
Price: $58.00
The Cove Series offers versatile LED recessed downlighting with a focus on innovative design and easy installation. Featuring a compact remote driver and IC Airtight UL-rated outlet box, Cove eliminates the need for traditional recessed housing, streamlining installation for residential and commercial applications. Its unique concave lens reduces glare by directing light upward, reflecting it back down to deliver smooth, even illumination. Available in multiple sizes, the Cove Series combines modern technology with sleek performance, offering a reliable solution for any lighting environment.


OPTIONS


Cove
Cove
SM567798WTWT
6" LED Recessed Downlight 4000K
Cove
Lamping
Number of Bulbs: 1
Light Type: LED
Bulb Type: PCB Integrated An average rating, in hours, indicating when 50% of a large group of lamps have failed, when operated at nominal lamp voltage and current; manufacturers use 3 hours per start for fluorescent lamps and 10 hours per start for HID lamps when performing lamp life testing procedures; every lamp type has a unique mortality curve that depicts its average rated life. For Photo-Optic specialty lamps, average rated life refers to the operating period after which on statistical average, 50% of the lamps will perform within their specified values.
Bulb Max Wattage: 12
Fixture Max Wattage: 12
Install Up/Down: Down
Rated Life: 40,000 Hours An average rating, in hours, indicating when 50% of a large group of lamps have failed, when operated at nominal lamp voltage and current; manufacturers use 3 hours per start for fluorescent lamps and 10 hours per start for HID lamps when performing lamp life testing procedures; every lamp type has a unique mortality curve that depicts its average rated life. For Photo-Optic specialty lamps, average rated life refers to the operating period after which on statistical average, 50% of the lamps will perform within their specified values.
Delivered Lumens: 1350 A measurement of the power of light emitted from a source. The difference between LED lumen versus lumens from an incandescent or fluorescent source is that all of the lumen output is directed forward as opposed to a bulb where lumens come off the source in all directions. Lumens are lost on the back side of a bulb.
Color Temperature: 4000 K This is a measurement in Kelvin of the color of light a source produces. Higher color temperatures (5,000 K or more) are cool (blueish white) colors; lower color temperatures (2,700–3,000 K) are warm (yellowish white through red) colors.
Bulb(s): Integrated
CRI: 90+
Dimmable: Yes
Input Voltage: 120

Measurements
Width: 6.75"
Height: 3.75"
Length: 6.75"
HCO: 3.8"
BP Height: 1.85"
Hanging Weight: 1.21 lb.
UPS Shippable: Yes Any box shipped via UPS that that is larger than 3 cubic feet in size will be charged shipping costs based on its dimensional weight rather than the actual weight of the package.

Certifications/Other
UL Standard: Damp
Meet California Title 24 Requirements: JA8 Listed Click for Additional Information on Title 24



SM567798
Cove
Cove
Cove 6" LED Recessed Downlight 4000K
Cove 6" LED Recessed Downlight 4000K
Cove 6" LED Recessed Downlight 4000K
Cove


Downloads
Assembly Insturctions - English DOWNLOAD
Specification Sheet DOWNLOAD
IES Photometric DOWNLOAD
Product Image
Infograph Sheet Download Web
Download Rep
Convert Brochure
Diverse Brochure
Parts and Accessories
Schematic Diagram
