Chips
5-Light Vertical Pendant - Brass
Chips
Model: SM32303SWNAB
Sizing: W34.5" x H38.5"
Finish: Natural Aged Brass
Shade: Satin White
Price: $3,630.00

Thinly curved panels of perforated metal shades are illuminated by LED globes of Satin White glass at various positions along the span of the suspended chip-like sculptures. The expansiveness of the panels are voluminous, yet seemingly airy in their perforated translucence. Influenced by pop art and sculpture, the Chips are functional lighting products comically named to express some of the personality in Mat Sanders' designs. The collection includes large scale pendants vertically or horizontally suspended, smaller scaled single pendants, and wall sconces. The shade panels are available in Natural Aged Brass and Matte White, but they can also be manufactured in RAL finishes chosen by Mat Sanders to match other Studio M Lighting items. Additional finishes by request include neutral Taupe or Grey hues and more dramatic hues of Dark Slate, mellow Sage Green, and softer Dusty Blush. Make it monochromatic or combine the finishes to create an illuminated art piece that matches your space.


OPTIONS


Chips
SM32303SWNAB
5-Light Vertical Pendant - Brass
Chips
Lamping
Number of Bulbs: 5

Light Type: LED

Bulb Type: G9
An average rating, in hours, indicating when 50% of a large group of lamps have failed, when operated at nominal lamp voltage and current; manufacturers use 3 hours per start for fluorescent lamps and 10 hours per start for HID lamps when performing lamp life testing procedures; every lamp type has a unique mortality curve that depicts its average rated life. For Photo-Optic specialty lamps, average rated life refers to the operating period after which on statistical average, 50% of the lamps will perform within their specified values.
Bulb Max Wattage: 4

Fixture Max Wattage: 20

Rated Life: 25,000 Hours
An average rating, in hours, indicating when 50% of a large group of lamps have failed, when operated at nominal lamp voltage and current; manufacturers use 3 hours per start for fluorescent lamps and 10 hours per start for HID lamps when performing lamp life testing procedures; every lamp type has a unique mortality curve that depicts its average rated life. For Photo-Optic specialty lamps, average rated life refers to the operating period after which on statistical average, 50% of the lamps will perform within their specified values.
Delivered Lumens: 1575
A measurement of the power of light emitted from a source. The difference between LED lumen versus lumens from an incandescent or fluorescent source is that all of the lumen output is directed forward as opposed to a bulb where lumens come off the source in all directions. Lumens are lost on the back side of a bulb.
Color Temperature: 3000 K
This is a measurement in Kelvin of the color of light a source produces. Higher color temperatures (5,000 K or more) are cool (blueish white) colors; lower color temperatures (2,700–3,000 K) are warm (yellowish white through red) colors.
Bulb(s): Included

CRI: 90

Measurements
Width: 34.5"

Height: 38.5"

Max Overall Height: 82"

Min Overall Height: 46"

Wire Length: 120"

Hanging Weight: 17.5 lb.

UPS Shippable: Oversize
Any box shipped via UPS that that is larger than 3 cubic feet in size will be charged shipping costs based on its dimensional weight rather than the actual weight of the package.
Canopy Width: 5"
Canopy Height: 0.75"

Certifications/Other
UL Standard: Dry

Meet California Title 24 Requirements: JA8 Bulb In
Click for Additional Information on Title 24



SM32303
Chips
Chips
Chips 5-Light Vertical Pendant - Brass
Chips 5-Light Vertical Pendant - Brass
Chips 5-Light Vertical Pendant - Brass
Chips 5-Light Vertical Pendant - Brass
Chips 5-Light Vertical Pendant - Brass
Chips


Downloads
Assembly Insturctions - English DOWNLOAD
Specification Sheet DOWNLOAD
IES Photometric DOWNLOAD
Product Image
Infograph Sheet Download Web
Download Rep
Convert Brochure
Diverse Brochure
Parts and Accessories
Schematic Diagram
